MDIO Register Interface
Figure 10 shows the MDI register interface.
Figure 10: MDI Register Interface
Management Data Clock
The Management Data Clock (MDC) is driven by the MAC sublayer. The PHY will sink this signal to synchronize
data transfer on the MDIO signal—MDC is a reference clock. This clock is not functionally associated to either
RX_CLK or TX_CLK. The minimum period for this clock is 400 ns with high and low times having 160 ns
duration.
Management Data Input/Output
The Management Data Input/Output (MDIO) signal passes control and status data, between the MAC and PHY
sublayers. MDIO is a bidirectional signal, meaning both the PHY and MAC may transfer data. The MAC typically
transfers control information and polls status; whereas, the PHY transfers status back to the MAC, using MDIO.
Management Data Interrupt
The integrated Broadcom PHY may be programmed to generate interrupts. A PHY status change initiates a
Management Data Interrupt (MDINT). A MDI mask register allows host software to selectively enable/disable
status types, which cause MDINT notification. The PHY will assert INTR
until software clears the interrupt.
Reading the status register will clear the interrupt.
Management Register Block
The layout and configuration of MDI register block is device dependent. The MDI register block is the control/
status access point, which host software may read/write. The IEEE 802.3 specification defines a basic register
block for MII and GMII; the basic register set contains control and status registers. GMII also exposes an
extended register set, used in 1000 Mbps configuration/status. The fundamental point is to understand that the
MDC and MDIO signals are used to access the MDI register block.
MAC Sublayer
Mgmnt
I/O
Mgmnt
Control
(MII & GMII)
Physical Layer
Mgmnt
I/O
Mgmnt
Control
MDC
MDIO
MDINT
MDI
Register
block
