Receive List Placement Rules Array
The Receive List Placement Rules Array (memory offset 0x480–0x4ff) is made up of 16 combined element
registers. The combined element is actually two 32-bit registers called the Receive BD Rules Control register
(see Table 22 ) and the Receive BD Rules Value/Mask register (see Table 24 on page 97). The element can be
looked at as a single 64-bit entity with a Control part and Value/Mask part since they use a single element. Bit
26 of the control part determines how the value/mask part is used. The Receive BD Rules Value/Mask register
can be used as either a 32-bit left-justified Value or a 16-bit Mask followed by a 16-bit Value.
Note: Receive rules cannot be used to match VLAN headers because the VLAN tag is stripped from
the Ethernet frame before the rule checker runs.
Table 22: Receive BD Rules Control Register
Table 23: Receive List Placement Rules Array (memory offset 0x480–0x4ff)
Bit Name RW Description Default
31 E RW Enable. Enabled if set to 1 –
30 & RW And With Next. This rule and next must both be true to match. The class
fields must be the same. A disabled next rule is considered true.
Processor activation bits are specified in the first rule in a series.
–
29 P1 RW If the rule matches, the processor is activated in the queue descriptor for
the Receive List Placement state machine.
–
28 P2 RW If the rule matches, the processor is activated in the queue descriptor for
the Receive Data and Receive BD Initiator state machine.
–
27 P3 RW If the rule matches, the processor is activated in the queue descriptor for
the Receive Data Completion state machine.
–
26 M RW Mask If set, specifies that the value/mask field is split into a 16-bit value
and 16-bit mask instead of a 32-bit value.
–
25 D RW Discard Frame if it matches the rule. –
24 Map RW Map Use the masked value and map it to the class. –
23:18 Reserved RW Must be set to zero. 0
17:16 Op RW Comparison Operator specifies how to determine the match:
• 00 = Equal
• 01 = Not Equal
• 10 = Greater than
• 11 = Less Than
–
