Broadcom NetXtreme/NetLink BCM5718 Series User Manual

IntroductionBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 47
Section 1: Introduction
The NetXtreme and NetLink family of Media Access Controller (MAC) devices are highly-integrated, single-chip
Gigabit Ethernet LAN controller solutions for high-performance network applications. These devices integrate
the following major functions to provide a single-chip solution for Gigabit LAN-on-motherboard (LOM) and
network interface card (NIC) applications.
• Triple-speed IEEE 802.3-compliant MAC functionality
• Triple-speed IEEE 802.3-compliant Ethernet PHY transceiver
• PCI Express (PCIe) bus interface
• On-chip packet buffer memory
• On-chip RISC processor for custom frame processing
Product Features
Table 2: BCM5718 Family Product Features
Feature
BCM5717
Dual-Port
Copper
BCM5718
Dual-Port
Copper/SerDes
BCM5719
Quad-Port
Copper/SerDes
BCM5720
Dual-Port
Copper/SerDes
Data Management
VLAN tag support (IEEE 802.1Q) Yes Yes Yes Yes
Layer 2 priority encoding (IEEE 802.1p) Yes Yes Yes Yes
Link aggregation (IEEE 802.3ad) Yes Yes Yes Yes
Full-duplex flow control (IEEE 802.3x) Yes Yes Yes Yes
Programmable rules checker for
advanced packet filtering and
classification
YesYesYesYes
Frame/packet buffer memory 32 KB RX,
29 KB TX
32 KB RX,
29 KB TX
40 KB RX,
29 KB TX
40 KB RX,
29 KB TX
TCP checksum offload (hardware
based) on Tx/Rx over IPv4/IPv6
YesYesYesYes
UDP checksum offload (hardware
based) on Tx/Rx over IPv4/IPv6
YesYesYesYes
IP checksum offload on Tx/Rx over
IPv4/IPv6
YesYesYesYes
Hardware TCP segmentation offload
over IPv4/IPv6
YesYesYesYes
Jumbo frame support Yes Yes Yes Yes
Receive-side scaling (RSS) Yes Yes Yes Yes
UDP Receive-side scaling (UDP RSS) No No Yes Yes
Transmit-side scaling (TSS) Yes Yes Yes Yes
