Broadcom NetXtreme/NetLink BCM5718 Series User Manual

Central Power Management Unit (CPMU) RegistersBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 395
Disable Energy_Det De-
bounce Low
5 RW 0x1 This bit is used to disable the
Energy_Det_Debounce_Low Logic from
debouncing the GPHY Energy_Det_APD signal
going low. When disabled, the Energy_Det signal
will go low if the GPHY Energy_Det input signal
is low for at least 640 ns.
0: Enable De-bounce Low
1: Disable De-bounce Low
Disable Energy_Det De-
bounce High
4 RW 0x1 This bit is used to disable the
Energy_Det_Debounce_High Logic from
debouncing the GPHY Energy_Det_APD signal
going high. When disabled, the Energy_Det
signal will go high if the GPHY Energy_Det input
signal is high for at least 640 ns.
0: Enable De-bounce High
1: Disable De-bounce High
Energy_Det De-bounce High
Limit
3:2 RW 0x0 This parameter is used to control the debounce
limit of the GPHY Energy_Det_APD signal going
high.
00: 128 million CPMU clocks (5 seconds if CPMU
clock frequency is 25 MHz)
01: 256 million CPMU clocks (10 seconds if
CPMU clock frequency is 25 MHz)
10: 512 million CPMU clocks (20 seconds if
CPMU clock frequency is 25 MHz)
11: 1024 million CPMU clocks (40 seconds if
CPMU clock frequency is 25 MHz)
Energy_Det De-bounce Low
Limit
1:0 RW 0x1 This parameter is used to control the debounce
limit of the GPHY Energy_Det_APD signal going
low.
00: 128 million CPMU clocks (5 seconds if CPMU
clock frequency is 25 MHz)
01: 256 million CPMU clocks (10 seconds if
CPMU clock frequency is 25 MHz)
10: 512 million CPMU clocks (20 seconds if
CPMU clock frequency is 25 MHz)
11: 1024 million CPMU clocks (40 seconds if
CPMU clock frequency is 25 MHz)
Name Bits Access
Default
Value
Description
