Transceiver Register MapBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 498
1Ch Miscellaneous_Shadow_Registers:
00000 => Cabletron LED modes
00001 => DLL Control
00010 => Spare Control 1
00011 => Clock Aligner
00100 => Spare Control 2
00101 => Spare Control 3
00110 => TDR Control 1
00111 => TDR Control 2
01000 => Led Status
01001 => Led Control
01010 => Auto-Power Down
01011 => External Control 1
01100 => External Control 2
01101 => LED Selector 1
01110 => LED Selector 2
01111 => LED GPIO Control/Status
10000 => Reserved
10001 => SerDes 100-FX Status
10010 => SerDes 100-FX Test
10011 => SerDes 100-FX Control
10100 => External SerDes Control
10101 => SGMII Slave Control
10110 => Misc 1000X Control 2
10111 => Misc 1000X Control
11000 => Auto-Detect SGMII/GBIC
11001 => Test 1000X
11010 => Autoneg 1000X Debug
11011 => Auxiliary 1000X Control
11100 => Auxiliary 1000X Status
11101 => Misc 1000X Status
11110 => Auto-Detect Medium
11111 => Mode Control
1Dh Master_Slave_Seed_Register
Shadow Register:
1 => HCD Status
1Eh Test1_Register
1Fh Test2_Register
(Cont.)
Address Name
To Next Page
