BCM5719 Register MapBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 588
HC 0x3C00–0x3FFF 0x3C00–0x3CC3 Host Coalescing
0x3CC4–0x3FFF Multiqueue HC
MA 0x4000–0x43FF 0x4000–0x400F Memory Arbiter
0x4010–0x43FF Unused
BM 0x4400–0x47FF 0x4400–0x445B Buffer manager
0x445C–0x47FF Unused
DMAR 0x4800–0x4BFF 0x4800–0x4910 DMAR LSO channel
0x4A00–0x4AFF DMAR BD channel
0x4B00–0x4BFF DMAR non-LSO channels
DMAW 0x4C00–0x4FFF 0x4C00–0x4C07 DMA Write
0x4C08–0x4FFF Unused
RX-CPU 0x5000–0x53FF 0x5000–0x5037 RX CPU
0x5038–0x53FF Unused
VRQ Filter-EMAC 0x5400–0x57FF 0x5400–0x55FF VRQ Filter Set
0x5600–0x568F VRQ Mapper
0x5690–0x572F VRQ Perfect Match Registers
0x5730–0x57FF Unused
MB 0x5800–0x5BFF 0x5800–0x5903 Low Priority Mail Box
0x5903–0x5BFF Unused
FTQ 0x5C00–0x5FFF 0x5C00–0x5CFF Flow Through Queue
0x5D00–0x5FFF Unused
MSI 0x6000–0x63FF 0x6000–0x6007 Message Signaled Interrupt
0x6008–0x63FF Unused
CFG Port 0x6400–0x67FF 0x6400–0x67FF PCIe Core Private Registers Access to
Configuration Space
GRC 0x6800–0x6BFF 0x6800–0x681B Misc Host Control
0x6834–0x6843 SEEPROM
0x6890–0x68A8 Misc Control
0x68B4–0x68EF E Switch
ASF 0x6C00–0x6FFF 0x6C00–6C37 ASF & SMBUS
0x6C38–0x6FFF Unused
NVM 0x7000–0x73FF 0x7000–0x703B Non Volatile memory (Flash Controller)
0x703C–0x73FF Unused
UART 0x7800–0x7BFF 0x7800–0x781F Debug UART Modem
0x7820–0x7BFF Unused
TL-DL-PL Port 0x7C00–0x7FFF 0x7C00–0x7FFF PCIe Core Private Register Access to TL,
DL & PL
Registers below are outside Host Standard View
APE 0x10000–0x18FFF – APE Access
MF 0x19000–0x193FF – Management Filters
Table 160: BCM5719 Register Map (Cont.)
Block Name Block Range Sub-Block Range Description
