BCM5720 Register MapBCM5718 Programmer’s Guide
Broadcom®
January 29, 2016 • 5718-PG108-R Page 592
DMAR 0x4800 – 0x4BFF 0x4800 – 0x4910 DMAR LSO channel
0x4A00 – 0x4AFF DMAR BD channel
0x4B00 – 0x4BFF DMAR non-LSO channels
DMAW 0x4C00 -0x4FFF 0x4C00 – 0x4C07 DMA Write
0x4C08 – 0x4FFF Unused
RX-CPU 0x5000 – 0x53FF 0x5000 – 0x5037 RX CPU
0x5038 – 0x53FF Unused
VRQ Filter-EMAC 0x5400 – 0x57FF 0x5400 – 0x55FF VRQ Filter Set
0x5600 – 0x568F VRQ Mapper
0x5690 – 0x572F VRQ Perfect Match Registers
0x5730 – 0x57FF Unused
MB 0x5800 – 0x5BFF 0x5800 – 0x5903 Low Priority Mail Box
0x5903 – 0x5BFF Unused
FTQ 0x5C00 – 0x5FFF 0x5C00 – 0x5CFF Flow Through Queue
0x5D00 – 0x5FFF Unused
MSI 0x6000 – 0x63FF 0x6000 – 0x6007 Message Signaled Interrupt
0x6008 – 0x63FF Unused
CFG Port 0x6400 – 0x67FF 0x6400 – 0x67FF PCIe Core Private Registers Access to
Configuration Space
GRC 0x6800 – 0x6BFF 0x6800 – 0x681B Misc Host Control
0x6834 – 0x6843 SEEPROM
0x6890 – 0x68A8 Misc Control
0x68B4 – 0x68EF E Switch
ASF 0x6C00 – 0x6FFF 0x6C00 – 6C37 ASF & SMBUS
0x6C38 – 0x6FFF Unused
NVM 0x7000 – 0x73FF 0x7000 – 0x703B Non Volatile memory (Flash Controller)
0x703C – 0x73FF Unused
UART 0x7800 – 0x7BFF 0x7800 – 0x781F Debug UART Modem
0x7820 – 0x7BFF Unused
TL-DL-PL Port 0x7C00 – 0x7FFF 0x7C00 – 0x7FFF PCIe Core Private Register Access to TL,
DL & PL
The registers below are outside Host Standard View.
APE 0x10000 – 0x18FFF – APE Access
MF 0x19000 – 0x193FF – Management Filters
Table 162: BCM5720 Register Map (Cont.)
Block Name Block Range Sub-Block Range Description
