C
HAPTER
40
| LLDP Commands
– 1316 –
EXAMPLE
Note that an IP phone or other end-node device which advertises LLDP-
MED capabilities must be connected to the switch for information to be
displayed in the “Device Class” field.
Console#show lldp info remote-device
LLDP Remote Devices Information
Interface Chassis ID Port ID System Name
--------- ----------------- ----------------- ---------------------
Eth 1/1 00-E0-0C-00-00-FD 00-E0-0C-00-01-02
Console#show lldp info remote-device detail ethernet 1/1
---------------------------------------------------------------
Local Port Name : Eth 1/2
Chassis Type : MAC Address
Chassis ID : 70-72-CF-18-B7-E0
Port ID Type : MAC Address
Port ID : 70-72-CF-18-B7-E1
System Name :
System Description : ES3528MV2
Port Description : Ethernet Port on unit 0, port 1
SystemCapSupported : Bridge
SystemCapEnabled : Bridge
Remote Management Address :
192.168.0.5 (IPv4)
Remote Port VID : 1
Remote Port-Protocol VLAN :
VLAN-3 : supported, enabled
Remote VLAN Name :
VLAN-1 : DefaultVlan
Remote Protocol Identity (Hex) :
88-CC
Remote MAC/PHY Configuration Status :
Remote port auto-neg supported : Yes
Remote port auto-neg enabled : Yes
Remote port auto-neg advertised cap (Hex) : 0000
Remote port MAU type : 6
Remote Power via MDI :
Remote power class : PSE
Remote power MDI supported : Yes
Remote power MDI enabled : Yes
Remote power pair controllable : No
Remote power pairs : Spare
Remote power classification : Class1
Remote Link Aggregation :
Remote link aggregation capable : Yes
Remote link aggregation enable : No
Remote link aggregation port ID : 0
Remote Max Frame Size : 1518
LLDP-MED Capability :
Device Class : Type Not Defined
Console#
