C
HAPTER
13
| Security Measures
IPv4 Source Guard
– 402 –
◆ IP Address – IP address corresponding to the client.
◆ Lease Time – The time for which this IP address is leased to the client.
(This value is zero for all static addresses.)
WEB INTERFACE
To configure static bindings for IP Source Guard:
1. Click Security, IP Source Guard, Static Configuration.
2. Select Add from the Action list.
3. Enter the required bindings for each port.
4. Click Apply
Figure 221: Configuring Static Bindings for IP Source Guard
To display static bindings for IP Source Guard:
1. Click Security, IP Source Guard, Static Configuration.
2. Select Show from the Action list.
Figure 222: Displaying Static Bindings for IP Source Guard
