C
HAPTER
14
| Basic Administration Protocols
Switch Clustering
– 486 –
◆ Number of Members – The current number of Member switches in the
cluster.
◆ Number of Candidates – The current number of Candidate switches
discovered in the network that are available to become Members.
WEB INTERFACE
To configure a switch cluster:
1. Click Administration, Cluster.
2. Select Configure Global from the Step list.
3. Set the required attributes for a Commander or a managed candidate.
4. Click Apply
Figure 280: Configuring a Switch Cluster
CLUSTER MEMBER
CONFIGURATION
Use the Administration > Cluster (Configure Member - Add) page to add
Candidate switches to the cluster as Members.
CLI REFERENCES
◆ "Switch Clustering" on page 766
PARAMETERS
These parameters are displayed:
◆ Member ID – Specify a Member ID number for the selected Candidate
switch. (Range: 1-36)
◆ MAC Address – Select a discovered switch MAC address from the
Candidate Table, or enter a specific MAC address of a known switch.
