C
HAPTER
15
| IP Configuration
Setting the Switch’s IP Address (IP Version 6)
– 575 –
WEB INTERFACE
To general IPv6 settings for the switch:
1. Click IP, IPv6 Configuration.
2. Select Configure Interface from the Action list.
3. Specify the VLAN to configure, enable address auto-configuration, or
enable IPv6 explicitly to automatically configure a link-local address
and enable IPv6 on the selected interface. Set the MTU size, the
maximum number of duplicate address detection messages, the
neighbor solicitation message interval, and the remote node reachable
time.
4. Click Apply.
Figure 334: Configuring General Settings for an IPv6 Interface
To configure RA Guard for the switch:
1. Click IP, IPv6 Configuration.
2. Select Configure Interface from the Action list.
3. Select RA Guard mode.
4. Enable RA Guard for untrusted interfaces.
5. Click Apply.
