Freescale Semiconductor PowerPC e500 Core - Page 498

Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-18 Freescale Semiconductor
mulhw.
011111 rD rA rB / 0010010111
X mulhw.
mulhwu
011111 rD rA rB / 0000010110
X mulhwu
mulhwu.
011111 rD rA rB / 0000010111
X mulhwu.
mulli
000111 rD rA SIMM
D mulli
mullw
011111 rD rA rB 00111010110
X mullw
mullw.
011111 rD rA rB 00111010111
X mullw.
mullwo
011111 rD rA rB 10111010110
X mullwo
mullwo.
011111 rD rA rB 10111010111
X mullwo.
nand
011111 rS rA rB 01110111000
X nand
nand.
011111 rS rA rB 01110111001
X nand.
neg
011111 rD rA /// 00011010000
X neg
neg.
011111 rD rA /// 00011010001
X neg.
nego
011111 rD rA /// 10011010000
X nego
nego.
011111 rD rA /// 10011010001
X nego.
nop nop equivalent to ori 0,0,0 nop
nor
011111 rS rA rB 00011111000
X nor
nor.
011111 rS rA rB 00011111001
X nor.
not not rA,rS equivalent to nor rA,rS,rS not
or
011111 rS rA rB 01101111000
X or
or.
011111 rS rA rB 01101111001
X or.
orc
011111 rS rA rB 01100111000
X orc
orc.
011111 rS rA rB 01100111001
X orc.
ori
011000 rS rA UIMM
D ori
oris
011001 rS rA UIMM
D oris
rfci
010011 /// 0000110011 /
XL rfci
rfi
010011 /// 0000110010 /
XL rfi
rfmci
010011 /// 0000100110 /
XL rfmci
rlwimi
010100 rS rA SH MB ME Rc
M rlwimi
rlwimi.
010100 rS rA SH MB ME Rc
M rlwimi.
rlwinm
010101 rS rA SH MB ME 0
M rlwinm
rlwinm.
010101 rS rA SH MB ME 1
M rlwinm.
rlwnm
010111 rS rA rB MB ME Rc
M rlwnm
rlwnm.
010111 rS rA rB MB ME Rc
M rlwnm.
Table D-1. Instructions (Binary) by Mnemonic
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
