Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
Freescale Semiconductor D-19
rotlw rotlw rA,rS,rB equivalent to rlwnm rA,rS,rB,0,31 rotlw
rotlwi rotlwi rA,rS,
n equivalent to rlwinm rA,rS, n ,0,31 rotlwi
rotrwi rotrwi rA,rS,
n equivalent to rlwinm rA,rS,32 – n ,0,31 rotrwi
sc
010001 /// 1 /
SC sc
slw
011111 rS rA rB 00000110000
X slw
slw.
011111 rS rA rB 00000110001
X slw.
slwi slwi rA,rS,
n (n < 32) equivalent to rlwinm rA,rS, n ,0,31 – n slwi
sraw
011111 rS rA rB 11000110000
X sraw
sraw.
011111 rS rA rB 11000110001
X sraw.
srawi
011111 rS rA SH 11001110000
X srawi
srawi.
011111 rS rA SH 11001110001
X srawi.
srw
011111 rS rA rB 10000110000
X srw
srw.
011111 rS rA rB 10000110001
X srw.
srwi srwi rA,rS,
n (n < 32) equivalent to rlwinm rA,rS,32 – n , n ,31 srwi
stb
100110 rS rA D
D stb
stbu
100111 rS rA D
D stbu
stbux
011111 rS rA rB 00111101110
X stbux
stbx
011111 rS rA rB 00110101110
X stbx
sth
101100 rS rA D
D sth
sthbrx
011111 rS rA rB 1110010110 /
X sthbrx
sthu
101101 rS rA D
D sthu
sthux
011111 rS rA rB 0110110111 /
X sthux
sthx
011111 rS rA rB 0110010111 /
X sthx
stmw
101111 rS rA D
D stmw
stw
100100 rS rA D
D stw
stwbrx
011111 rS rA rB 1010010110 /
X stwbrx
stwcx.
011111 rS rA rB 00100101101
X stwcx.
stwu
100101 rS rA D
D stwu
stwux
011111 rS rA rB 0010110111 /
D stwux
stwx
011111 rS rA rB 0010010111 /
D stwx
sub sub rD,rA,rB equivalent to subf rD,rB,rA sub
subc subc rD,rA,rB equivalent to subfc rD,rB,rA subc
subf
011111 rD rA rB 00001010000
X subf
Table D-1. Instructions (Binary) by Mnemonic
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
