Freescale Semiconductor PowerPC e500 Core - Page 500

Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-20 Freescale Semiconductor
subf.
011111 rD rA rB 00001010001
X subf.
subfc
011111 rD rA rB 00000010000
X subfc
subfc.
011111 rD rA rB 00000010001
X subfc.
subfco
011111 rD rA rB 10000010000
X subfco
subfco.
011111 rD rA rB 10000010001
X subfco.
subfe
011111 rD rA rB 00100010000
X subfe
subfe.
011111 rD rA rB 00100010001
X subfe.
subfeo
011111 rD rA rB 10100010000
X subfeo
subfeo.
011111 rD rA rB 10100010001
X subfeo.
subfic
001000 rD rA SIMM
D subfic
subfme
011111 rD rA /// 00111010000
X subfme
subfme.
011111 rD rA /// 00111010001
X subfme.
subfmeo
011111 rD rA /// 10111010000
X subfmeo
subfmeo.
011111 rD rA /// 10111010001
X subfmeo.
subfo
011111 rD rA rB 10001010000
X subfo
subfo.
011111 rD rA rB 10001010001
X subfo.
subfze
011111 rD rA /// 00110010000
X subfze
subfze.
011111 rD rA /// 00110010001
X subfze.
subfzeo
011111 rD rA /// 10110010000
X subfzeo
subfzeo.
011111 rD rA /// 10110010001
X subfzeo.
subi subi rD,rA,value equivalent to addi rD,rA,–value subi
subic subic rD,rA,value equivalent to addic rD,rA,–value subic
subic. subic. rD,rA,value equivalent to addic. rD,rA,–value subic.
subis subis rD,rA,value equivalent to addis rD,rA,–value subis
tlbivax
011111 /// rA rB 1100010010 /
X tlbivax
tlbre
011111 ///
9
1110110010 /
X tlbre
tlbsx
011111 /// rA rB 1110010010 /
X tlbsx
tlbsync
011111 /// 1000110110 /
X tlbsync
tlbwe
011111 /// 1111010010 /
X tlbwe
tw
011111 TO rA rB 0000000100 /
X tw
tweq tweq rA,SIMM equivalent to tw 4,rA,SIMM tweq
tweqi tweqi rA,SIMM equivalent to twi 4,rA,SIMM tweqi
twge twge rA,SIMM equivalent to tw 12,rA,SIMM twge
Table D-1. Instructions (Binary) by Mnemonic
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
