Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
Freescale Semiconductor D-21
twgei twgei rA,SIMM equivalent to twi 12,rA,SIMM twgei
twgt twgt rA,SIMM equivalent to tw 8,rA,SIMM twgt
twgti twgti rA,SIMM equivalent to twi 8,rA,SIMM twgti
twi
000011 TO rA SIMM
D twi
twle twle rA,SIMM equivalent to tw 20,rA,SIMM twle
twlei twlei rA,SIMM equivalent to twi 20,rA,SIMM twlei
twlge twlge rA,SIMM equivalent to tw 12,rA,SIMM twlge
twlgei twlgei rA,SIMM equivalent to twi 12,rA,SIMM twlgei
twlgt twlgt rA,SIMM equivalent to tw 1,rA,SIMM twlgt
twlgti twlgti rA,SIMM equivalent to twi 1,rA,SIMM twlgti
twlle twlle rA,SIMM equivalent to tw 6,rA,SIMM twlle
twllei twllei rA,SIMM equivalent to twi 6,rA,SIMM twllei
twllt twllt rA,SIMM equivalent to tw 2,rA,SIMM twllt
twllti twllti rA,SIMM equivalent to twi 2,rA,SIMM twllti
twlng twlng rA,SIMM equivalent to tw 6,rA,SIMM twlng
twlngi twlngi rA,SIMM equivalent to twi 6,rA,SIMM twlngi
twlnl twlnl rA,SIMM equivalent to tw 5,rA,SIMM twlnl
twlnli twlnli rA,SIMM equivalent to twi 5,rA,SIMM twlnli
twlt twlt rA,SIMM equivalent to tw 16,rA,SIMM twlt
twlti twlti rA,SIMM equivalent to twi 16,rA,SIMM twlti
twne twne rA,SIMM equivalent to tw 24,rA,SIMM twne
twnei twnei rA,SIMM equivalent to twi 24,rA,SIMM twnei
twng twng rA
,SIMM equivalent to tw 20,rA,SIMM twng
twngi twngi rA,SIMM equivalent to twi 20,rA,SIMM twngi
twnl twnl rA,SIMM equivalent to tw 12,rA,SIMM twnl
twnli twnli rA,SIMM equivalent to twi 12,rA,SIMM twnli
wrtee
011111 rS /// 0010000011 /
X wrtee
wrteei
011111 /// E /// 0010100011 /
X wrteei
xor
011111 rS rA rB 01001111000
X xor
xor.
011111 rS rA rB 01001111001
X xor.
xori
011010 rS rA UIMM
D xori
xoris
011011 rS rA UIMM
D xoris
1
Simplified mnemonics for branch instructions that do not test a CR bit should not specify one; a programming error may occur.
Table D-1. Instructions (Binary) by Mnemonic
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
