Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
Freescale Semiconductor D-33
mullwo.
31 (0x1F) rD rA rB 10111010111
X mullwo.
nand
31 (0x1F) rS rA rB 01110111000
X nand
nand.
31 (0x1F) rS rA rB 01110111001
X nand.
neg
31 (0x1F) rD rA /// 00011010000
X neg
neg.
31 (0x1F) rD rA /// 00011010001
X neg.
nego
31 (0x1F) rD rA /// 10011010000
X nego
nego.
31 (0x1F) rD rA /// 10011010001
X nego.
nor
31 (0x1F) rS rA rB 00011111000
X nor
nor.
31 (0x1F) rS rA rB 00011111001
X nor.
or
31 (0x1F) rS rA rB 01101111000
X or
or.
31 (0x1F) rS rA rB 01101111001
X or.
orc
31 (0x1F) rS rA rB 01100111000
X orc
orc.
31 (0x1F) rS rA rB 01100111001
X orc.
slw
31 (0x1F) rS rA rB 00000110000
X slw
slw.
31 (0x1F) rS rA rB 00000110001
X slw.
sraw
31 (0x1F) rS rA rB 11000110000
X sraw
sraw.
31 (0x1F) rS rA rB 11000110001
X sraw.
srawi
31 (0x1F) rS rA SH 11001110000
X srawi
srawi.
31 (0x1F) rS rA SH 11001110001
X srawi.
srw
31 (0x1F) rS rA rB 10000110000
X srw
srw.
31 (0x1F) rS rA rB 10000110001
X srw.
stbux
31 (0x1F) rS rA rB 00111101110
X stbux
stbx
31 (0x1F) rS rA rB 00110101110
X stbx
sthbrx
31 (0x1F) rS rA rB 1110010110 /
X sthbrx
sthux
31 (0x1F) rS rA rB 0110110111 /
X sthux
sthx
31 (0x1F) rS rA rB 0110010111 /
X sthx
stwbrx
31 (0x1F) rS rA rB 1010010110 /
X stwbrx
stwcx.
31 (0x1F) rS rA rB 00100101101
X stwcx.
stwux
31 (0x1F) rS rA rB 0010110111 /
D stwux
stwx
31 (0x1F) rS rA rB 0010010111 /
D stwx
subf
31 (0x1F) rD rA rB 00001010000
X subf
subf.
31 (0x1F) rD rA rB 00001010001
X subf.
subfc
31 (0x1F) rD rA rB 00000010000
X subfc
Table D-2. Instructions (Decimal and Hexadecimal) by Opcode
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
