Freescale Semiconductor PowerPC e500 Core - Page 514

Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-34 Freescale Semiconductor
subfc.
31 (0x1F) rD rA rB 00000010001
X subfc.
subfco
31 (0x1F) rD rA rB 10000010000
X subfco
subfco.
31 (0x1F) rD rA rB 10000010001
X subfco.
subfe
31 (0x1F) rD rA rB 00100010000
X subfe
subfe.
31 (0x1F) rD rA rB 00100010001
X subfe.
subfeo
31 (0x1F) rD rA rB 10100010000
X subfeo
subfeo.
31 (0x1F) rD rA rB 10100010001
X subfeo.
subfme
31 (0x1F) rD rA /// 00111010000
X subfme
subfme.
31 (0x1F) rD rA /// 00111010001
X subfme.
subfmeo
31 (0x1F) rD rA /// 10111010000
X subfmeo
subfmeo.
31 (0x1F) rD rA /// 10111010001
X subfmeo.
subfo
31 (0x1F) rD rA rB 10001010000
X subfo
subfo.
31 (0x1F) rD rA rB 10001010001
X subfo.
subfze
31 (0x1F) rD rA /// 00110010000
X subfze
subfze.
31 (0x1F) rD rA /// 00110010001
X subfze.
subfzeo
31 (0x1F) rD rA /// 10110010000
X subfzeo
subfzeo.
31 (0x1F) rD rA /// 10110010001
X subfzeo.
tlbivax
31 (0x1F) /// rA rB 1100010010 /
X tlbivax
tlbre
31 (0x1F) ///
4
1110110010 /
X tlbre
tlbsx
31 (0x1F) ///
4
rA rB 1110010010/
4
X tlbsx
tlbsync
31 (0x1F) /// 1000110110 /
X tlbsync
tlbwe
31 (0x1F) ///
4
1111010010 /
X tlbwe
tw
31 (0x1F) TO rA rB 0000000100 /
X tw
wrtee
31 (0x1F) rS /// 0010000011 /
X wrtee
wrteei
31 (0x1F) /// E /// 0010100011 /
X wrteei
xor
31 (0x1F) rS rA rB 01001111000
X xor
xor.
31 (0x1F) rS rA rB 01001111001
X xor.
lwz
32 (0x20) rD rA D
D lwz
lwzu
33 (0x21) rD rA D
D lwzu
lbz
34 (0x22) rD rA D
D lbz
lbzu
35 (0x23) rD rA D
D lbzu
stw
36 (0x24) rS rA D
D stw
stwu
37 (0x25) rS rA D
D stwu
Table D-2. Instructions (Decimal and Hexadecimal) by Opcode
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
