Opcode Listings
PowerPC e500 Core Family Reference Manual, Rev. 1
D-48 Freescale Semiconductor
evstwwex
000100 rS rA rB 01100111000
EVX evstwwex
evstwwo
000100 rS rA UIMM
4
01100111101
EVX evstwwo
evstwwox
000100 rS rA rB 01100111100
EVX evstwwox
evsubfsmiaaw
000100 rD rA /// 10011001011
EVX evsubfsmiaaw
evsubfssiaaw
000100 rD rA /// 10011000011
EVX evsubfssiaaw
evsubfumiaaw
000100 rD rA /// 10011001010
EVX evsubfumiaaw
evsubfusiaaw
000100 rD rA /// 10011000010
EVX evsubfusiaaw
evsubfw
000100 rD rA rB 01000000100
EVX evsubfw
evsubifw
000100 rD UIMM rB 01000000110
EVX evsubifw
evxor
000100 rD rA rB 01000010110
EVX evxor
b
010010 LI 00
I b
ba
010010 LI 10
I ba
bl
010010 LI 01
I bl
bla
010010 LI 11
I bla
rlwimi
010100 rS rA SH MB ME Rc
M rlwimi
rlwimi.
010100 rS rA SH MB ME Rc
M rlwimi.
rlwinm
010101 rS rA SH MB ME 0
M rlwinm
rlwinm.
010101 rS rA SH MB ME 1
M rlwinm.
rlwnm
010111 rS rA rB MB ME Rc
M rlwnm
rlwnm.
010111 rS rA rB MB ME Rc
M rlwnm.
sc
010001 /// 1 /
SC sc
mfpmr
011111 rD PMRN5–9 PMRN0–4 01010011100
XFX mfpmr
mfspr
011111 rD SPRN5–9 SPRN0–4 0101010011 /
XFX mfspr
mtcrf
011111 rS / CRM / 0010010000 /
XFX mtcrf
mtpmr
011111 rS PMRN5–9 PMRN0–4 01110011100
XFX mtpmr
mtspr
011111 rS SPRN5–9 SPRN0–4 0111010011 /
XFX mtspr
bcctr
010011 BO BI /// 10000100000
XL bcctr
bcctrl
010011 BO BI /// 10000100001
XL bcctrl
bclr
010011 BO BI /// 00000100000
XL bclr
bclrl
010011 BO BI /// 00000100001
XL bclrl
crand
010011 crbD crbA crbB 0100000001 /
XL crand
crandc
010011 crbD crbA crbB 0010000001 /
XL crandc
creqv
010011 crbD crbA crbB 0100100001 /
XL creqv
Table D-3. Instructions (Binary) by Form
Mnemonic
012345678910111213141516171819202122232425262728293031
Form Mnemonic
