PowerPC e500 Core Family Reference Manual, Rev. 1

Freescale Semiconductor D-49

crnand

010011 crbD crbA crbB 0011100001 /

XL crnand

crnor

010011 crbD crbA crbB 0000100001 /

XL crnor

cror

010011 crbD crbA crbB 0111000001 /

XL cror

crorc

010011 crbD crbA crbB 0110100001 /

XL crorc

crxor

010011 crbD crbA crbB 0011000001 /

XL crxor

isync

010011 /// 0010010110 /

XL isync

mcrf

010011 crfD // crfS /// 0000000000 /

XL mcrf

rfci

010011 /// 0000110011 /

XL rfci

rfi

010011 /// 0000110010 /

XL rfi

rfmci

010011 /// 0000100110 /

XL rfmci

This field is defined as allocated by the Book E architecture, for possible use in an implementation. These bits are not implemented in

the e500.

d = UIMM * 8

d = UIMM * 2

d = UIMM * 4

Table D-3. Instructions (Binary) by Form

Mnemonic

012345678910111213141516171819202122232425262728293031

Form Mnemonic
