1 Creating WindO/I-NV3 Project Data
3-8 SmartAXIS Touch User's Manual
● Print Tab
■ Printer
■ Print Range
Select the items you want to print.
When the following items are selected, their tabs are displayed.
■ Copies
■ Printing Font
Displays the Font dialog box. You can change the font used when printing.
Name: Select a printer connected to the computer or Save As RTF file on disk.
You can output an RTF-formatted file by selecting Save As RTF file on disk.
Set path of RTF file: When outputting an RTF-formatted file, click this button to display the
Save As dialog box. Specify the saved location, file name, and then
click OK.
Status: Shows the current status of the printer.
Type: Shows the manufacturer and model of the printer.
Location: Shows the destination or the location to save the file.
Comment: Shows a comment entered in the Printer Properties dialog box.
Project Settings: Prints the project settings.
Screen Settings: Prints the screen settings, a list of the parts on the screen, and a screen image. The details are
configured on the Screen tab.
Part List: Prints the settings for all parts used in the project.
Device List: Prints the settings for all devices used in the project.
Picture List: Prints the images and settings for drawing objects registered in Picture Manager. The details are
configured on the Picture tab.
Library List: Prints the settings and images for Library Screens. The details are configured on the Library tab.
Text List: Prints all the text registered in Text Manager.
Script List: Prints all the scripts registered in Script Manager.
Protocol List: Prints the settings for Protocols registered in Protocol Manager. The details are configured on the
Protocol tab.
Item Reference
Screen Settings “Screen Tab” on page 3-9
Picture List “Picture Tab” on page 3-10
Library List “Library Tab” on page 3-11
Protocol List “Protocol Tab” on page 3-12
Number of copies: Enter the number of copies to print (1 to 100).
To Next Page
