SmartAXIS Touch User's Manual 24-25
2 Monitoring on the Touch
24
Monitor Function
â– Operation button
Details: Displays detailed information for the selected instruction. Select an instruction on the ladder
program and press to display. The displayed content varies based on the instruction.
Example:
Label: Shows the name and data type of the instruction.
Instruction: Shows the instruction name up to a maximum of 5 characters.
Data type: Shows the data type. The displayed data types are as follows.
W (word), I (integer), D (double word), L (long), F (float)
Parameter: Shows the configuration details for the instruction.
OPCODE: MOV (W)
S1 -: D0000 = 1234
D1 R: D0123 = 1234
REP : 03
/
99
Parameter
Label
Instruction Data type
:
Moves the focus right by one line.
:
Moves the focus left by one line.
:
Moves the focus up by one line.
:
Moves the focus down by one line.
:
Toggles the contact state for the selected NO contact or NC contact.
Press and hold to display the detailed information for the instruction with focus.
:
The operation varies based on the content displayed in the display.
Ladder program: Closes the Ladder Monitor.
Details: Closes the detailed information screen.
To Next Page
