SmartAXIS Touch User's Manual 2-13
1 WindO/I-NV3 Specifications
2
WindO/I-NV3 Basic Operations
● Windows Font
Selecting Windows Font for the Font property gives you access to all of the fonts installed on your computer for use
on Drawings and Parts. This allows you to display fonts and languages that are not installed on the Touch.
Windows Font Settings
Windows Font settings are made in the Font Settings dialog box.
1 Click Change in the Windows Font group on the properties dialog box for Drawings, Parts, or on Text Manager.
2 Set each item, and then click OK.
■ Font
Select the font to use.
■ Font style
Select italic, bold, or other style.
■ Size
Select the size of the text.
■ Sample
Shows a preview using the specified font.
■ Character Pitch
Specify character spacing from 0 to 100.
■ Space between lines
Specify line spacing from 0 to 100.
■ Script
Select the character set code.
• The right end of the text may have missing dots if Font style is set to Italic. You can remedy this by
adding an extra space at the end of the line.
• An alternate font will be used if the Project Data uses a font that does not exist on the computer. This
means that text will appear differently if the Project Data is opened on another computer.
• The same font may also appear differently for different OS versions.
