SmartAXIS Touch User’s Manual 9-31
2 Character Input
9
Data Displays
■ Display Character with “*”
*1
Select this check box to display the entered characters as * (asterisks).
If this check box is selected, nothing is displayed until a value is entered from the key buttons or keypad when the
Character Input is in entry mode. If ENT is pressed with nothing displayed, 0 is written to the destination device.
■ Change Font with Device
*1
Select this check box to change the font to display the text with a value of device.
The keypad (Popup Screen) can also be changed when Standard or Popup is selected for Type under Keypad on
the General tab.
*1 Advanced mode only
Trigger Device: Specifies the word device (2 words) to use as the condition to change the font.
Click to display the Device Address Settings dialog box. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Example: With Trigger Device set to D100, to enter Central European text from Popup Screen
100 using a Character Input for entering European text from the standard keypad
(Popup Screen 3003)
Write 6 to D100 and 100 to D101.
Font number Popup Screen No.
1st word 3rd word2nd word
Font number
1. Japanese
2. European
6. Central European
7. Baltic
8. Cyrillic
Popup Screen
No.
1 to 3015
To Next Page
