SmartAXIS Touch User’s Manual 9-57
4 Message Display
9
Data Displays
■ Message
Enter the text to display. The maximum number is 610 characters. You can enter multi-line messages by inserting a
newline. To configure text to display according to values of devices, enter “\@” (1 to 8) at the location to read the
values of word devices as character codes and display them as text. The channels configured under Data are
allocated in order from the first “\@”. The text is displayed according to the values of devices in order from the first
reference device.
Example: The device configured in Ch1 is allocated to the first “\@”. The device configured in Ch2 is allocated to the
second “\@”.
The characters that can be entered vary based on to the font selected for Font on the Format tab. For details, refer
to Chapter 2 “1.3 Available Text” on page 2-6.
This option can only be configured if the Use Text Manager check box is cleared.
■ Data
These options are used to register or edit the devices with values to read as character codes.
Now \
Goal \
Always show Show according to values of devices
Ch1
Ch2
• To enter Unicode characters, click to display the Unicode Input dialog box. Enter the characters in
the Unicode Input dialog box, and then click OK.
• To display the backslash (\), enter a backslash (\) before the backslash (\).
Example:\\
(Settings): Lists the settings for the text to display according to values of devices.
No.: Shows the channel numbers (Ch1 to Ch8).
Device: Shows the reference device configured for the channel.
Words: Shows the number of words used by the reference device.
Reference Device: Specifies the word device that stores the values read as character codes.
Click to display the Device Address Settings dialog box. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Set the values of devices to the character codes for the language used. For details, refer to
Chapter 2 “Character Code Table” on page 2-15.
Words: Specifies the number of words for the length of the text to display (1 to 64). Values of devices
for the configured amount of words are read as character codes starting from the device
address set by Reference Device. 2 single-byte characters can be displayed by 1 word.
Set: Registers the settings for the text to display according to values of devices to the list. If you
select a number that is already registered, that number is overwritten with the new settings.
Select a Ch number on the list, and then click this button to register the Reference Device
and Words settings.
Always register the settings from Ch1.
Insert: Inserts the settings in the position selected on the list.
Select a Ch number on the list, and then click this button to insert the Reference Device and
Words settings. The settings at the insertion point shift down one line. Settings cannot be
inserted if all the Ch numbers are configured.
Remove: Deletes the registered settings from the list.
Select a Ch number, and then click this button to delete the selected settings from the list.
To Next Page
