5 Message Switching Display
9-74 SmartAXIS Touch User’s Manual
● Message Tab
■ Use Text Manager
Select this check box to use text registered in Text Manager.
■ Settings
Lists the message settings.
■ Text ID
Specifies the Text Manager ID number (1 to 32000) when using text registered in Text Manager.
Click to display Text Manager.
This option can only be configured when the Use Text Manager check box is selected.
■ Message
Enter the text to display. The maximum number is 3,750 characters. You can enter multi-line messages by inserting a
newline.
The characters that can be entered vary based on the font selected for Font on the Format tab. For details, refer to
Chapter 2 “1.3 Available Text” on page 2-6.
This option can only be configured if the Use Text Manager check box is cleared.
No.: Shows the message number (Msg number).
The number of messages that can be registered varies based on Switching Method on the
General tab.
Bit: Msg0 to Msg15
Value: Msg0 to Msg999
Message: Shows the registered message.
Change: Shows Y when the Change Color check box is selected. Shows N when the check box is
cleared.
Text: Shows the text color of the message.
Plate: Shows the plate color.
• To enter Unicode characters, click to display the Unicode Input dialog box. Enter the characters in
the Unicode Input dialog box, and then click OK.
• To display the backslash (\), enter a backslash (\) before the backslash (\).
Example: \\
