SmartAXIS Touch User's Manual 2-21
1 WindO/I-NV3 Specifications
2
WindO/I-NV3 Basic Operations
The graphic element is saved in Picture Manager. The name of the image file becomes the picture name.
Even when the image is saved to a different category, if a graphic element of the same name is already
saved in that category, a confirmation message to overwrite the file is displayed.
•Click Yes to overwrite the image.
After overwriting, the image is saved in the list of the selected category, and the previous image is deleted
from the list.
Example: The graphic element "Picture00" is saved in the category "Pic_Lib."
If the graphic element "Picture00.bmp" is saved to the category "NewBook1," the new image
"Picture00" is saved to "NewBook1," and the image named "Picture00" that was previously in
"Pic_Lib" is deleted.
•Click No to stop saving the graphic element.
