SmartAXIS Touch User’s Manual 10-51
4 Meter
10
Charts
■ Data Format
■ Reference Device
Specifies the source word device for the data to display in the meter.
Click to display the Device Address Settings dialog box. For the device address configuration procedure, refer to
Chapter 2 “5.1 Device Address Settings” on page 2-62.
Data Type: Selects the data type handled by the meter.
For details, refer to Chapter 2 “1.2 Available Data” on page 2-2.
Minimum, Maximum: Specifies the minimum and maximum for the data.
The minimum and maximum vary based on the selected data type. For details, refer to
Chapter 2 “1.2 Available Data” on page 2-2.
The needle does not move past the left edge when the data value is the minimum or
lower.
The needle stops at the right edge when the data value is the maximum or higher.
If BCD4 is selected for Data Type and the read data contains A through F, 1 is written to System Area 2
Arithmetic error bit (address+2, bit 5), and an error message is displayed. For details, refer to Chapter 3
“Arithmetic error” on page 3-25.
