● Week Programmer FB
● Script FB
● Special FB
Symbol Name and Diagram Function
Output
Inversion
WEEK
Weekly Timer
Compares the specified day of the week, ON time,
and OFF time with the current time and outputs
the result.
NO
YEAR
Yearly Timer
Compares the specified date with the current date
and outputs the result.
NO
WEEK
EN OUT
INI
YEAR
EN OUT
INI
Symbol Name and Diagram Function
Output
Inversion
SCRPT
Script
Enables you to program complicated processing
with the script language that supports conditional
branching, logical operations, arithmetic
operations, and functions.
NO
SCRPT
EN OUT
Symbol Name and Diagram Function
Output
Inversion
HSC
High-speed Counter
Operates the high-speed counter configured in
the function area settings. Turns on/off the high-
speed counter gate input/clear input.
YES
RSFF
RS Flip-flop
When the set input turns on, the output turns on
and is kept on. When the reset input turns on, the
output turns off.
YES
HSC
GT OUT
RST
CLR
RSFF
SET OUT
RST
