IDEC SmartAXIS Touch FT1A Series User Manual

SmartAXIS Touch User's Manual 12-45
3 FBD Program
12
Control Function
● Available Data
The available data types for each FB are as follows.
*1 Analog inputs (AI0, AI1) do not support the word type. When using the analog input cartridge (AI2 to AI5), configure the AI
FB data type in the function area settings. For how to configure the function area settings, refer to Chapter 3 “4.15 Analog
Cartridge” on page 3-88.
In WindLDR data types are displayed as follows: BIN16(+) as W (word), BIN16(+/-) as I (integer),
BIN32(+) as D (double word), BIN32(+/-) as L (long), and float32 as F (float).
FB
Data type
W I D L F
Word Integer
Double
word
Long FloatGroup Name Symbol
Input
Digital Input I NO NO NO NO NO
Special Internal Relay SM NO NO NO NO NO
Shift Register R NONONONONO
Analog Input AI
YES
*1
YES
*1
NO NO NO
Output
Digital Output Q NONONONONO
Internal Relay M NO NO NO NO NO
Logical Operation
Logical AND AND NO NO NO NO NO
Negative Logical AND NANDNONONONONO
Logical OR OR NO NO NO NO NO
Negative Logical OR NORNONONONONO
Exclusive Logical OR XORNONONONONO
Negative Exclusive Logical OR XNOR NO NO NO NO NO
Negation NOTNONONONONO
Shot Up SOTU NO NO NO NO NO
Shot Down SOTD NO NO NO NO NO
Truth Table TRUTH NO NO NO NO NO
Timer
On-delay Count Up Timer TIMU YES NO NO NO NO
On-delay Count Down Timer TIMD YES NO NO NO NO
Off-delay Count Up Timer TIMOU YES NO NO NO NO
Off-delay Count Down Timer TIMOD YES NO NO NO NO
On/off-delay Timer TIMCU YES NO NO NO NO
Single Shot Pulse SPULS YES NO NO NO NO
Dual Timer DTIM YES NO NO NO NO
Random Pulse Output RPULS YES NO NO NO NO
Counter
Adding Counter CNT YES NO YES NO NO
Up/Down Selection Reversible
Counter
CUD YES NO YES NO NO
Hour Meter HOUR YES NO NO NO NO
Shift Register Shift Register SFR NO NO NO NO NO
Data Comparison
Data Comparison CMP YES YES YES YES NO
Schmitt Trigger STTG YES YES YES YES NO
Range Comparison RCMP YES YES YES YES NO
Data ConversionAlternate Output ALTNONONONONO
Week Programmer
Weekly Timer WEEKNONONONONO
Yearly Timer YEARNONONONONO
Script Script SCRPT YES YES YES YES YES
Special
High-speed Counter HSC YES NO YES NO NO
RS Flip-flop RSFFNONONONONO
