4 Remote I/O
12-52 SmartAXIS Touch User's Manual
5 Configure IP Address and Port of the remote I/O slave to connect.
6 Click OK.
When the settings are correctly configured, the details configured in the Remote Host dialog box is displayed in
Remote Host No..
7 For Receive Timeout (ms), configure the receive timeout with the remote I/O slave.
8 Click OK.
Configuring the remote I/O master is completed.
The default port number of the remote I/O slave is 2110.
