SmartAXIS Touch User’s Manual 13-23
3 Alarm Log Settings Dialog Box
13
Alarm Log Function
• The function to sample data operates when Alarm Log data is being saved to the external memory.
• The methods to erase Alarm Log files saved on the external memory are as follows.
- To erase files during operation using parts, on the External Memory tab on the Project Settings dialog
box, select the Remove Files stored in External Memory check box and the All Alarm Log data
check box, and then configure the trigger device. Assign that trigger device to a part.
- To erase files with WindO/I-NV3, click Clear on the Online tab, and then click Stored Data in
External Memory to open the Clear Data dialog box. Select the Alarm Log Data check box, and then
click OK.
To Next Page
