SmartAXIS Touch User's Manual 2-47
3 Configuration & Functions
2
WindO/I-NV3 Basic Operations
● View
View is where you can switch the workspace display and display the Tag Editor, Screen Diagram, and various managers.
You can configure the items displayed in the editing window.
■ Workspace
■ Show/Hide
Command Description
Toolbox Shows the Toolbox window. This window displays Parts and Drawings.
Project Window
Shows the Project window. This window displays the saved screens and project
related information.
Screen List
Shows the Screen List window. The window displays the screens saved in the
project as thumbnails.
Object List
Shows the Object List window. This window displays all of the graphics and parts
placed in an editing screen.
Part List Shows the Part List window. This window displays the list of part images.
Tag Editor
Shows the Tag Editor. This window displays the list of registered device address, tag
name, and comments.
Screen Diagram
Shows the Screen Diagram. This window displays the Overlapping Screen
information, and the screen numbers and titles of the screens linked by the Goto
Screen Button, the Goto Screen Command, the Numerical Input, the Character
Input, the Alarm List Display and the Alarm Log Display.
Comparison Result
Shows the Comparison Result window. This window displays the results of that
comparison of projects.
Picture Manager Shows Picture Manager. Manages the registered images for project use.
Text Manager
Shows Text Manager. Manages registered text which can be used for Text, Part objects,
title of Popup Screen, messages with Alarm List Display and Alarm Log Display.
Script Manager Shows Script Manager. Manages registered scripts for project use.
Protocol Manager Shows Protocol Manager. Manages protocols created.
Control Function
Start up WindLDR. This is an editor for performing various control function settings
and creating ladder programs or FBD programs.
Command Description
Part Name Shows or hides drawing object names and part names.
Device Address Shows or hides device addresses and tag names.
Trigger Condition Shows or hides trigger conditions.
Commands Shows or hides the dotted frame for commands.
Popup Screen
Shows or hides a Popup Screen’s number, display frame, and the part name of the
part calling that Popup Screen.
Overlay Screens Shows or hides the configured overlay screens.
Security Group
Display Shows or hides the display security group set for parts.
Input Shows or hides the input security group set for parts.
Gridlines Shows or hides the gridlines in the editing window.
