3 Data Log Settings Dialog Box
14-24 SmartAXIS Touch User’s Manual
■ Target Data
Selects the data to copy from the Data Log data.
Example: When Start No. is 2 and End No. is 4, data 2 to 4 is the copy target.
■ Trigger Condition
Selects the condition to start copying.
Sampling Time: Select this check box to copy the sampling time data from the Data Log data. When this check
box is selected, values of devices are copied in order from the data for data number 1.
Value of Device: Select this check box to copy the value of device from the Data Log data.
Data No.: Selects the specification method for the data number of the value to copy.
Value: Uses a constant.
Device: Uses a word device.
Start No.: Of the data to copy, specifies the data number of the data to start
copying.
If you select Value, specify the data number (1 to 128).
If you select Device, specify the source device. You can only
specify an internal device. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on
page 2-62.
When the Sampling Time check box is selected, the data number
is 1. This cannot be changed.
End No.: Of the data to copy, specifies the data number of the data to end
copying.
If you select Value, specify the data number (1 to 128).
If you select Device, specify the source device. You can only
specify an internal device. For the device address configuration
procedure, refer to Chapter 2 “5.1 Device Address Settings” on
page 2-62.
Start No. End No.
Data No.: 1 2 3 4 5
↓↓↓↓↓
Sampling Time Data 1 Data 2 Data 3 Data 4 Data 5
10/01/2011 12:34:56 100 60 240 60 240
10/02/2011 03:45:12 200 80 450 80 450
Copy target
Always: Copies each time the data is updated.
Device: Specifies the device that triggers the start of copying the data. Copies the data when the value
of the specified device changes from 0 to 1.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-62.
