3 Data Log Settings Dialog Box
14
Data Log Function
■ Starting Point
Selects the starting point of the data to copy.
Example: 1. For Newest Data, the starting point is the newest sampling time data.
2. For Oldest Data, the starting point is the oldest sampling time data.
3. For Specify by Value of Device and source device: 3, the starting point is the third item of data from
the oldest sampling time data.
■ Number of Data
Selects the specification method for the amount of data to copy.
■ Stored Order of Data
Selects the order to copy data.
Example: When Starting Point is Newest Data and Number of Data is 3, data is copied in the following order
starting from device LDR10 configured in Destination Device.
Newest Data: Sets the starting point as the newest data.
Oldest Data: Sets the starting point as the oldest data.
Specify by Value of Device: Specifies which data from the oldest data to set as the starting point.
Specifies the source word device. You can only specify an internal device.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-62.
Data Log data
Sampling Time Value
2. Oldest Data read starting point → 12/18/2011 17:44:10 20
12/18/2011 18:34:10 21
3. Specify by Value of Device read starting point (source device: 3) → 12/19/2011 19:24:43 22
12/19/2011 20:01:54 24
12/19/2011 21:39:21 26
1. Newest Data read starting point → 12/20/2011 05:57:06 28
Value: Uses a constant.
Specifies the amount to copy (1 to 64).
Device: Uses a word device.
Specifies the source word device. You can only specify an internal device.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-62.
The maximum amount of data that can be copied to the internal device is 64.
From Newest to Oldest: Of the data to copy, copies from the start point in order of the newest data first.
From Oldest to Newest: Of the data to copy, copies from the start point in order of the oldest data first.
Data Log data
Sampling Time
Value
Destination Device
Value
12/18/2011 17:44:10
20
Configured device
→ LDR10 28 ←
Copy from newest data
11RDL:: 26
12/19/2011 19:24:43
21RDL22 24
12/19/2011 20:01:54
24
Newest data
read starting point
→
12/19/2011 21:39:21
26
12/20/2011 05:57:06
28
Destination Device
Value
Configured device
→ LDR10 24 ← Copy from oldest data
LDR11
26
LDR12
28
Amount of data: 3
