SmartAXIS Touch User’s Manual 18-7
2 Recipe Function Configuration Procedure
18
Recipe Function
17
Specify the device that triggers batch writing recipe values to devices in Write Trigger.
This option is set by block.
Click to display the Device Address Settings dialog box.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
This option can only be configured when Read/Write or Write-only is selected under Trigger Setting.
18
Click OK to close the Individual Settings dialog box.
19
Repeat steps 3 through
18
to register data for the recipe to all the used channels.
20
Click OK.
The Recipe Settings dialog box closes.
For details on how to create and edit the data for recipes, refer to “4 Creating and Deleting Data for Recipes” on page
18-14.
To Next Page
