4 Creating and Deleting Data for Recipes
18-18 SmartAXIS Touch User’s Manual
4 Specify the drive for USB flash drive, and then click OK.
■ Drive
Specifies the drive assigned to the external memory.
■ Network
Displays the Map Network Drive dialog box. This dialog box allows you to specify a drive on the network.
■ External Memory Folder
Specifies the folder to save the created recipe file.
Click to display the Project Settings dialog box. You can specify the External Memory Folder used as the save
destination.
5 Click OK.
The Recipe Settings dialog box closes.
The “RECIPE” folder is created in the External Memory Folder used as the save destination, and the recipe files for the
channels configured with Access to set to External Memory and Recipe function set to Enable in the Recipe
Settings dialog box are created.
To Next Page
