SmartAXIS Touch User’s Manual 18-19
4 Creating and Deleting Data for Recipes
18
Recipe Function
● Creating Recipe Files when Downloading Project Data
When a project download is executed, the “RECIPE” folder is created in the External Memory Folder on the external
memory inserted in the Touch and the recipe files are created. The recipe files are only created for channels
configured with Access to set to External Memory and Recipe function set to Enable in the Recipe Settings
dialog box.
1 Insert a USB flash drive into the Touch.
2 On the Home tab, in the Project group, click the Download icon.
The Download dialog box is displayed.
If the project data was changed, a confirmation message to save the project data is displayed.
Click OK to save the project data and display the Download dialog box.
Click Cancel to stop to save the project data.
3 Select the Download Recipe Files to External Memory check box.
The External Memory Folder is configured in the Project Settings dialog box. For details, refer to Chapter 26
“1.5 Setting the External Memory Folder” on page 26-12.
USB flash drive
Touch
To Next Page
