4 Creating and Deleting Data for Recipes
18-20 SmartAXIS Touch User’s Manual
4 Verify Communication Settings, and then click Download.
Since the recipe files are downloaded to the external memory inserted in the Touch, use the same settings as when
communicating with the Touch.
To change Communication Settings, click Change to display the Communication Settings dialog box. Change
Communicate with, Port, and Baud Rate. For details, refer to Chapter 23 “1 Communicating with the Touch” on
page 23-1.
5 Click Yes.
The Download Project dialog box is displayed and the project files start downloading.
When finished downloading, a completion message is displayed.
6 Click OK.
7 Click Close.
●
Creating Recipe Files with a Text Editor
You can edit recipe files using Notepad, commercially available text editors, or spreadsheet software.
1 Write the data for the amount of data in “value of device” comma (,) new line order.
If the amount of data in the recipe file is lower than the amount of data for the top device configured on the Channel
tab in the Individual Settings dialog box, 0 is written in the rest of the devices.
2 Save the file with the “.csv” extension.
Give the file the file name configured on the Block tab in the Individual Settings dialog box. If the file name is
different, 0 is written to all the devices.
3 Copy the edited recipe files to the “RECIPE” folder in the External Memory Folder on the external memory.
If security is enabled in the Touch project, the Password Screen is displayed. Select the user name and
enter the password.
For details, refer to Chapter 21 “User Accounts and the Security Function” on page 21-1.
To Next Page
