SmartAXIS Touch User’s Manual 21-29
2 Security Function Configuration Procedure
21
User Accounts and the Security Function
14
Click OK.
The Properties of Goto Screen Button dialog box closes.
This concludes configuring the project to protect the operation of a part.
Operating Procedure
This section describes an example when the current user account has no default user.
1 Press the Goto Screen Button configured with Open Password Screen.
The Password screen is displayed.
2 Press
▼
and select User2.
3 Enter the password.
1. Press ↑, ↓, ←, and → to move the cursor to the character selected and then press ENT.
2. Repeat 1 to enter all the characters for the password.
3. Press ↑, ↓, ←, and → to move the cursor to OK and then press ENT.
If the correct password is entered, the user account changes to User2 from no default user and the Password screen
closes.
The Numerical Input can be operated.
Press the Goto Screen Button.
No user
999
Touch
Password
ENT
▼
User2
BS CLR OK
A BCDEFGHIJKLM
NOPQRS T UVWXY Z
0123456789
Password
ENT
▼User2
*
BS CLR OK
ABCDEFGHIJKLM
NOPQRS T UVWXY Z
012 3456789
1
2
Password
ENT
▼
User2
********
BS CLR
ABCDEFGHIJKLM
NOPQRS T UVWXY Z
0123456789
OK
1
2
To Next Page
