SmartAXIS Touch User’s Manual 21-35
3 User Accounts Dialog Box
21
User Accounts and the Security Function
■ Status of Password Entry
Select this check box to monitor the entry status of the password on the Password screen.
The following bits change to 1 depending on the password input status. These bits become 0 when the Password
screen opens or when a button other than ENT or
(Close) is pressed on the Password screen.
■ Require a password automatically
Select this check box to automatically display the Password screen when the user attempts to switch to a Base Screen
that cannot be accessed with the current user account by using a Goto Screen Button or Goto Screen Command
configured with Switch to Base Screen for the Action Mode in the Properties dialog box.
(Destination device): Specifies a word device to write the password entry status.
Click to display the Device Address Settings dialog box. For the device address
configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-62.
Bit
position
Function Parameters
0
This bit stores the information when the correct password was
entered on the Password screen and ENT was pressed.
0: Password being entered
1: Correct password entered
1
This bit stores the information when an incorrect password was
entered on the Password screen and ENT was pressed.
0: Password being entered
1: Incorrect password entered
2
This bit stores the information when (Close) was pressed on
the Password screen.
0: Password being entered
1: Password entry canceled
3 to 7 Reserved –
