6. Web Menu System
6-49
Chapter6 Web Menu System
Display Contents
1)
Level
User with “Admin”
level can browse and set Admin menu located
in the [menu] panel of Web interface.
Level of the user is displayed on the [Headline] of Web interface.
2)
Name Name of the user.
This name is displayed on the [Headline] of Web interface and used in Call
Log. This field allows less than 10 alphanumeric characters.
3) Secret Code 4 digits. Range: 0001 to 9000
This code is used to log in (User Login) or to recognize the user when a
secret call was made.
4) Restriction Restriction of connections.
The Restrictions listed on this menu are set in [Sec. 6.5
Connection](p6-51).
When “Disable” is selected, communication of the user is unlimited.
5) WAN Profile WAN Profile used for data connections.
This profile arranges data connection (refer to [Sect. 6.4.2 Connect to the
Internet (p6-15)]) for the user.
For more information about WAN profile,
refer to [Sec. 6.5.5.1 Set WAN profile (p6-53)].
6) Multi Connect Permission to connect and to disconnect internet connection for someone
else on Data Connection screen.
7）
Quick Connect Permission to use “Quick Connect” on Dashboard screen.
8) Set Registers the user.
9) Del Deletes the user.
* Beware that once the data is deleted, it won’t be recovered again.
* User 01 is reserved for an Admin user. You can not delete it nor can edit its level.
* User 02 is reserved
for Guest user. You can not delete it nor can edit its level, name and
Secret Code.
Table 6.5.4.1 Contents of User Registration Screen
To Next Page
