3. Appearance
3. Appearance
In this section, the composition of the JUE-501/JUE-251 and terminal equipments are explained.
1) Above Deck Equipment (ADE): Antenna unit and radome (Antenna Cover)
2) Blow Deck Equipment (BDE): Main unit
3) Coaxial cable: A Cable connects ADE to BDE
4) Handset: Handset and cradle
5) Terminal equipments: Accessories used for communication (user supplied PC, FAX, and
telephone)
3.1 ADE
Radome covers the antenna equipments, which is composed of:
a) Low Noise Amplifier (LNA)
b) Above Deck Unit (ADU) contains GPS circuit.
c) Rotary joint
d) Antenna pedestal
All signals (and power) pass through a single coaxial cable, which connects the ADE and BDE.
Fig. 3.1 ADE
GSC-511 for JUE-501
GSC-251 for JUE-251
