6. Web Menu System
6-5
Chapter6 Web Menu System
Connect your PC to User LAN port of JUE-501/JUE-251
Connect your PC to User LAN port with Ethernet cable. JUE-501/JUE-251 recognizes the type of
Ethernet cable (cross or straight) automatically. A maximum of total 32W PoE (Power over Ethernet)
is available on User LAN.
To Access Web Menu
Launch
*1
your Web browser
*2
and enter [192.168.128.100]
*3
to the URL box. Then press [Enter] key.
*1
Your PC must be in the same network with main unit (refer to [Set your PC], P6-2).
*2
While JUE-501 / JUE-251 officially supports Microsoft Internet Explorer7 and Mozilla Firefox3.6,
their upper version can be available when they have compatible system.
*3
We explain here with the assumption of factory default. In practice, enter http://[main unit IP
Address]/ to the URL box of your Web browser.
RJ-45
Ethernet
cable
