6. Web Menu System
6-45
Chapter6 Web Menu System
＊
1
）
About IP address input
IP address is configured with period-separated 4 strings of numbers.
Example) 192.168.128.100 or 10.20.30.0
Possible input range of IP Address:
10. 0.0.1 – 10.255.255.254
172.16.0.1 – 172.31.255.254
192.168.0.1 – 192.168.255.254
＊
2
）
About DHCP
The range of IP address allocated by DHCP must not exceed network address defined
by parameter 1) and 2).
Port
Parameter
Value
User LAN
IP Address
192.168.128.100
Subnet Mask
255.255.255.0
DHCP
Enable
DHCP Start Address
192.168.128.101
DHCP Count
16
Ext WAN
IP Address
192.168.0.4
Subnet Mask
255.255.255.0
Table 6.5.3.3b Initial settings of Ethernet port
NOTE
・Use of “all ones” or “all zeros” for the host field of the IP address is not supported.
・192.168.0.0/24 is used for EXT WAN and 192.168.60.0/24 is used for JRC LAN as a default. To set
these addresses to User LAN, change the network address of EXT WAN or JRC LAN first and set
the address to User LAN.
