JRC JUE-501 User Manual

3. Appearance
3-12
Fig. 3.4.2 Functional button
section
Fig. 3.4.3
Alpha-numeric button section
3.4.2 Functional button section
This section describes function buttons except those for entering characters.
Buttons and its function
GH
3.4.3 Alpha-numeric button section
Buttons and usage
Enters # and also scrolls the screen to the right direction.
Enters* and also scrolls the screen to the left direction.
Enters numerical/alphabetical
characters and symbols.
Aa
STAT U S
W
0.,-
Switching button Switches enter mode, between alphabets and numbers.
SMS button Reads, creates, sends, and deletes Short Message Service（SMS).
Status button Makes direct access to STATUS menu.
OK
OK button Registers entered contents.
Scroll up button
Scrolls up the screen / makes direct access to Outgoing Calls List menu.
MENU
Menu button Makes direct access to TOP Menu.
Satellite button Makes direct access to Satellite menu.
Phonebook button Makes direct access to Phonebook menu.
CLR
Off Hook(Call starting)button Makes a call and receives a call.
Clear button Clears (cancels) the entry immediately before.
On Hook(Call finishing)button Hangs up the call.
Scroll down button
Scrolls down the screen/makes direct access to Incomming Calls List menu.
6MNO
#
3DEF
3DEF
W
9XYZ
2ABC
8TUV
5JKL
0.,-
1
*
P
7QRS
4GHI
This button has no function.
This button adjusts the
voice volume and the
screen brightness
of the
Handset.
SMS
FN button.
This button is used for call
waiting and call holding.
