Appendix H How to connect PPPoE Connection
H-11
H.4.3. Check the PPPoE connection
Check the PPPoE connection by sending ping packets or browsing Web pages.
If you cannot receive ping packets nor can browse Web pages, disconnect PPPoE connection and retry
PPPoE connection procedure.
Fig.H.4.3.1 Windows Command Prompt
H.5. PPPoE client option setting (Windows XP)
In the procedure of section H.4.1. (2), when Properties button is pressed, “Service name” in the
“General” tab is displayed. The detailed option can be specified for PPPoE connection in Service name.
The option is memorized by PC once it is specified.
Fig.H.5 PPPoE Client Properties dialog
