JRC JUE-501 User Manual

6. Web Menu System
6-16
1) Connection Status
Status of connection
2) Profile
Assigned profile
3) Connection Type
Available service type defined by assigned profile
4) Desire Rate
Desire Rate for the connection (Only for the streaming service)
5) Minimum Rate
Minimum Rate for the connection (Only for the streaming service)
Connection will be cut automatically when the communication
rate falls
below this rate.
6) Local IP
Local IP address for the connection.
* Other IP is available only when [Multi Connect] has been enabled for the
login user in User Registration [Sec. 6.5.4.1](p6-48
) or Device
Registration [Sec. 6.5.4.2](p6-50).
7) APN
* Access Name Point
8) APN User/Password
* User name and Password for APN.
The password will be hidden by ● when it entered.
9) Global IP
* Select Dynamic or Static for Global IP address used for this connection.
Input of Global IP address is required only when Static is selected.
10) Connect/Disconnect
Connect/Disconnect the connection
11) Connection Type
Connection type for the secondary service
12) Desire Rate
Desire Rate for the secondary connection (Only for the streaming service)
13) Minimum Rate
Minimum Rate for the secondary service (Only for the streaming service)
Secondary service will be cut automatically when the communication rate
falls below this rate
14) Connect/Disconnect
Connect/Disconnect the secondary connection
* 7) APN, 8) APN User/Password and 9) Global IP are editable only when the column of “Edit” on
WAN Profile screen is set to “Permitted”.
Fig. 6.4.2b Data Connection-Setting part
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
Table 6.4.2 Contents of Data Connection-Setting part
