11. Specification
11-1
Specification Chapter 11
11. Specification
JUE-501 (ADE, BDE)
1. Inmarsat FleetBroadband MES type
Class 8
2. Frequency Transmission
1626.5 to 1660.5 MHz, 1668.0 to 1675.0 MHz
Reception
1518.0 to 1559.0 MHz
3. Maximum E.I.R.P
+22.0dBW + 1/-2dB
4. G/T (Reception capacity)
-7.0dBK
5. Antenna Type
54cm
flat
Polarization
Right-Hand Circular Polarization (RHCP)
Beam width
22degrees, in 3dB down direction
Radome
Glass Fiber Reinforced Plastics (GFRP)
6. Modulation
O-QPSK
For voice
π
/4-QPSK
16QAM
7. Primary power Voltage
Connecting with EXT PSU:100/110 or
89VAC to 266VAC
+21.6VDC to +31.2VDC
Current
2 A or less in reception
Maximum
6.5A or less in transmission with
connecting option
Compass Safe
Distance
Standard Compass : 0.6m
Steering Compass: 0.7m
8. Dimension ADE
630mm × h683mm
BDE
h65mm
×
w262mm
×
d275mm
9. Mass ADE
20kg
BDE
4.5kg
10. Environmental conditions
1) Temperature ADE
-25˚C to +55˚C
BDE
-25˚C to +55˚C (Handset -15˚C to +55˚C)
2) Relative humidity
Up to +40˚C, 95%
3) Oscillation Compliance with IEC60945 4th edition
4) Ship's motion
Motion Amplitude
Period
Roll
+30˚
8 s
Pitch +10˚ 6 s
Yaw
+8˚
50 s
Surge +0.2g
Sway
+0.2g
Heave +0.5g
