Appendix D
Softw
are updating procedure
D-3
D.2. Update soft
ware
Note
・
Do not turn OFF the powe
r supply of JUE
-
50
1/JUE
-
251
and/or PC during the sof
tware forwarding or
updating
・
Applica
tion
-s
oftware
forwarding or updat
ing takes u
p to
3
minutes
.
・
Main
-
software updati
ng can not
be perform
ed in main mode.
1.
Click [So
ftware Updat
e] on the left
[menu] panel.
・
[Software U
pdate] screen w
ill be displayed.
2.
Click
[Browse]
button
.
Then
file selection
dialog will a
ppear
.
294
296
