PROGRAM > AL-1: OSC/Pitch 4–3: Mixer
149
AMS [List of AMS Sources]
This selects an AMS source to control the Oscillator 1
Balance. For a list of AMS sources, see “Alternate
Modulation Source (AMS) List” on page 901.
Intensity [–99…+99]
This controls the depth and direction of the Oscillator 1
Balance AMS modulation.
Phase Invert [Off, On]
This inverts the phase of Oscillator 1.
4–3b: OSC2
Oscillator 2 has the same mixer parameters as described
under “4–3a: OSC1,” above.
4–3c: Sub OSC/Audio Input
In addition to the Level, Balance, AMS, and Phase Invert
parameters described under “4–3a: OSC1,” above, this
section has controls for using an external audio input.
Mode [Sub OSC, External Audio Input]
This selects whether the mixer input will be used for the Sub
Oscillator, or the audio input selected below.
External Audio [Audio Inputs 1, 2, USB 1, 2]
This selects the audio input used for both this mixer channel
and the Ring Modulator.
The Ring Modulator can use the selected audio input even if
Mode, above, is set to Sub OSC.
4–3d: Ring Mod
The Ring Modulator has the same mixer parameters as
described under “4–3a: OSC1,” above.
4–3e: Noise
The Noise Generator has the same mixer parameters as
described under “4–3a: OSC1,” above.
v
4–3: Page Menu Commands
• Compare →p.112
• Write Program →p.112
• Exclusive Solo →p.113
• PAGE →p.126
• MODE →p.126
